Minnich A-4SC - On Grade Attachment A10321-00002

- 55 -
Form: MM-
A
4/A5SC Revised 07/13/16
FIG. PART NUMBER DESCRIPTION QTY
A 0A8422-00000 WELDM’T, ADJUSTMENT SCREW 1
A 007132-00000 COIL NUT 1
A 006155-00000 LOCKWASHER, 3/4 1
B 0A9960-00002 WELDM’T, DRILL BED HEIGHT ADJUSTMENT 1
C 004463-00008 PLATE, MOUNTING 1
C 006040-4.000 HHCS, 1/2-13 X 4 GR.5 4
C 006406-00000 LOCKNUT, 1/2-13 4
D 0A9999-00004 WELDM’T, LIFT ANCHOR ADAPTOR 1
E 0A9958-00000 WELDM’T, DRILL BED EXTENSION TUBE 1
F 007102-00002 CHAIN, 3/16 CLOSE LINK 13
F 006038-1.250 HHCS, 3/8-16 X 1-1/4 GR.5 1
F 006106-00000 FLATWASHER 5/16 3
F 006404-00000 LOCKNUT 3/8-16 2
F 006038-1.750 HHCS, 3/8-16 X 1-3/4 GR.5 1
G 006038-1.500 HHCS, 3/8-16 X 1-1/2 GR.5 3
G 006106-00000 FLATWASHER 5/16 3
G 006404-00000 LOCKNUT 3/8-16 3
H 004303-00001 CASTER WHEEL, RIGID 1
