Minnich A-4SC - General Specifications

- 6 -
Form: MM-
A
4/A5SC Revised 07/13/16
*Based on 2 piece steel and bits. Whirlybits should be 1” (2.5cm) longer for maximum drilling depth.
GENERAL SPECIFICATIONS CONT
Pneumatic Connection:
 An approved air disconnect is required to be installed in accordance to all Local and National
Codes.
Environmental:
 +5°C to +40°C (+41°F to +104°F)
 50% Rh at +40°C (+104°F), (90% Rh at +20°C (+68°F))
 Altitude – 1000m (3280ft) above mean sea level
 Unit is to be disposed according to all Local and National Regulations
Transportation and Storage:
 -25°C to +55°C for 24 hours (-13°F to +131°F)
Ingress Protection:
 Protection level IP2X is provided
Sound:
 System operates at sound levels about 85dBA and 85dBC. Hearing protection is required.
System Nameplate:
