Minnich A-4SC - Page 25

- 25 -
Form: MM-
A
4/A5SC Revised 07/13/16
Plumbing Diagram (Part 2)
FIG. PART NUMBER DESCRIPTION QT
Y
A 010829-00005 FITTING, ELBOW 5/32 TUBE - 1/8 MALE NPT (1 LESS FOR A-4SC) 11
B 010831-00004 FITTING, MALE TEE 5/32 TUBE 1/8 NPT (2 LESS FOR A-4SC) 8
C 010923-00000 LIMIT VALVE, MARKER 1
D 010842-00002 FITTING, 1/4 Y – TUBE TO TUBE 4
E 010825-00003 FITTING, 5/32 TUBE TO MALE NPT (2 LESS FOR A-4SC) 11
F 012135-00000 BREATHER VENT (2 LESS FOR A-4SC) 14
G 010917-00000 VALVE, AIR TOGGLE 2 POSITION IN LINE (2 LESS FOR A-4SC) 14
H 010829-00009 FITTING, MALE ELBOW 1/4 TUBE TO 1/8 MALE NPT 5
I 010434-00000 SWIVEL JOINT 1
J 011879-00000 REWORKED, ELBOW 90 DEG EXT PIPE/37 24-24 1
K 006000-00012 NIPPLE, PIPE 3/8 CLOSE SCH 80 1
L 011874-00011 SWIVEL, NUT ADAPTOR 1
M 006000-00061 NIPPLE, PIPE 2” CLOSE SCH 40 1
N 008988-00000 COUPLING, GROUND JOINT SEAL 1
O 003834-00001 LUBRICATOR 1
P 006000-00017 NIPPLE, PIPE 1-1/2 X 2 SCH 80 1
Q 011703-00000 REGULATOR, AIR 1
R 006680-00004 END, HOSE 37 DEG FEMALE SWIVEL / BARBED 24-24 1
R 006681-00004 CLAMP HOSE, HEAVY DUTY 1
R1 006682-00005 END, HOSE MALE PIPE / BARBED 24-24 1
R1 006681-00004 CLAMP HOSE, HEAVY DUTY 1
S 006019-00032 ELBOW, 90 DEG EXT PIPE/37 DEG 20-24 1
T 006015-00003 TEE, INTERNAL PIPE 06-06 1
U 006296-00001 BUSHING, REDUCER PIPE 06-04 2
V 006007-00012 CONNECTOR, 37 DEG MALE/PIPE 06-06 2
W 006032-00005 END, HOSE 37 DEG FEM SWIVEL / BARBED 06 1
X 010829-00010 FITTING, MALE ELBOW 1/4 TUBE TO 1/4 MALE NPT 3
Y 006019-00024 ELBOW, 90 DEG EXT PIPE / 37 DEG 12-12 4
Z 011163-00009 ADAPTER, SWIVEL NUT 1/2-14 TO 1-1/16-12 (1 LESS FOR A-4SC) 5
AA 010925-00000 VALVE (1 LESS FOR A-4SC) 5
BB 006296-00016 BUSHING, REDUCER PIPE 04-02 (1 LESS FOR A-4SC) 5
CC 006007-00019 CONNECTOR, 37 DEG MALE/PIPE 08-12 (1 LESS FOR A-4SC) 5
DD 006032-00006 END, HOSE 37 DEG FEM SWIV BARBED 12 (2 LESS FOR A-4SC) 11
EE 011321-00012 TEE, RUN EXT PIPE/37 DEG 12-12 1
FF 007612-00005 MANIFOLD 2
FF 006036-3.500 HHCS, 1/4-20 X 3-1/2 4
FF 006147-00000 1/4 LOCKWASHER 4
FF 006104-00000 1/4 FLATWASHER 4
FF 006070-00000 1/4-20 HEXNUT 4
GG 006471-00007 PLUG, PIPE HEX SOC 20 1
HH 006471-00003 PLUG, PIPE HEX SOC 06 3
II 006471-00004 PLUG, PIPE HEX SOC 08 1
JJ 006471-00005 PLUG, PIPE HEX SOC 12 1
KK 006471-00002 PLUG, PIPE HEX SOC 1/4 1
LL 006000-00016 NIPPLE, PIPE 1-1/4 X 1-3/4 SCH 80 1
MM 006032-00002 END, HOSE 37 DEG FEM SWIV/BARBED 08 2
NN 006019-00017 ELBOW, 90 DEG EXT PIPE/37 DEG 08-08 2
OO 006016-00007 ELBOW, 90 DEG EXT/INT PIPE 06-06 1
PP 006296-00015 BUSHING, REDUCER PIPE 06-02 1
QQ 004955-00000 FILTER 1
RR 010836-00006 FITTING, STRAIGHT FEMAILE CONNECTOR 1/4 TUBE TO 1/8 NPT 1
SS 006466-00001 NIPPLE, PIPE STEEL 02-02 1
TT 006296-00003 BUSHING, REDUCER 1
UU 006011-00007 PLUG, CAP 1
VV 003819-00001 HOSE, AIR 1-1/2 ID 19
WW 002304-00000 HOSE, AIR 1/2” ID 40
XX 010863-00000 TUBING, NYLON 1/4 BLACK SEMI-RIGID 134
YY 010861-00000
TUBING, NYLON 5/32 BLACK SEMI-RIGID
(
68 LESS FOR A-4SC
)
460
ZZ 003997-00000
HOSE, 3/4 ID, 200 PSI (216 LESS FOR A-4SC)
946
AZ 001807-00000 HOSE, 3/8 AIR 40
