- 27 -
Form: MM-
4/A5SC Revised 07/13/16
Plumbing Diagram (Part 3)
FIG. PART NUMBER DESCRIPTION QTY
A 010829-00005 FITTING, M ELBOW 5/32 TUBE TO 1/8 M NPT (1 LESS FOR A-4SC) 6
B 010829-00010 FITTING, M ELBOW 1/4 TUBE TO 1/4 M NPT (1 LESS FOR A-4SC) 9
C 011700-00000 BLOCKING PLUG 3
D 006296-00001 BUSHING, REDUCER PIPE 06-04 (1 LESS FOR A-4SC) 7
E 010825-00008 FITTING, 1/4 TUBE TO 1/4 MALE NPT (2 LESS FOR A-4SC) 14
F 006007-00012 CONNECTOR, 37 DEG MALE/PIPE 06-06 1
G 011531-00000 MANIFOLD, 6 STATION 1
G 006257-1.750 #10-24 X 1-3/4 SLOTTED 4
G 006145-00000 #10 LOCKWASHER 4
G 006102-00000 #12 FLATWASHER 4
G 006654-00000 #10-24 HEXNUT 4
G 011549-00000 VALVE, AIR (1 LESS FOR A-4SC) 6
G 011532-00000 COVER, BLANK STATION (A-4SC ONLY) 1
H 006010-00006 END, HOSE MALE PIPE/BARBED 06-08 3
J 006032-00002 END, HOSE 37 DEG FEM SWIVEL/BARBED 08 3
K 006019-00012 ELBOW, 90 DEG EXT PIPE/37 DEG 06-08 3
L 010829-00009 FITTING, MALE ELBOW 1/4 TUBE TO 1/8 MALE NPT 1
M 002880-00000 REGULATOR, AIR 1
N 006471-00001 PLUG (SUPPLIED WITH 002880-00000 AIR REGULATOR) 1
O 010836-00007 FITTING, STRAIGHT FEMAL CONNECTOR 1/4 TUBE TO 1/4 NPT 2
P 007059-00001 AIR GUAGE (LOW PRESSURE) 1
Q 007059-00000 AIR GUAGE (HIGH PRESSURE) 1
R 006296-00002 BUSHING, REDUCER PIPE 08-04 2
T 011992-00016 CYLINDER, AIR 7 X 16 1
U 011740-00020 CYLINDER, AIR 2-1/2 X 20 (1 LESS FOR A-4SC) 5
V 010829-00011 FITTING, M ELBOW 1/4 TUBE TO 3/8 M NPT (1 LESS FOR A-4SC) 5
W 006032-00005 END, HOSE 37 DEG FEM SWIV/BARBED 06 1
X 010863-00000 SLEEVING (139 LESS FOR A-4SC) 614
WW 002304-00000 HOSE, AIR 1/2” ID 136
XX 010836-00000 TUBING, NYLON 1/4 BLACK SEMI-RIGID (308 LESS FOR A-4SC) 1517
YY 010861-00000 TUBING, NYLON 5/32 BLACK SEMI-RIGID (20 LESS FOR A-4SC) 100
