Mira FORM - INSTALLATION REQUIREMENTS; System Compatibility and Symbols

10
Key to Symbols
INSTALLATION REQUIREMENTS
Gravity Fed Shower - The shower MUST be fed from a cold water cistern and hot
water cylinder providing nominally equal pressure.
Mixing Valve
Twin Impeller Pump
Tempering Valve
Pressure Reducing Valve
Single Impeller Pump
Overflow
Float operated valve
Mini expansion vessel
Isolating Valve
