6
DIMENSIONS
DIMENSIONS
600 mm
283 mm
max.
75 mm
184.5 mm
251 mm
152 mm
310 mm
6-21 mm when
front mounted onto
a solid, stud wall
4-19 mm when
rear mounted onto
a panel wall
100 mm
80 mm
62 mm
