Mircom FX-3500 - Appendix F - Battery Calculations

100
13.0 Appendix F - Battery Calculations
IMPORTANT NOTICE
The main AC branch circuit connection for Fire Alarm Control Unit must provide a dedicated continuous power without provision of any
disconnect devices. Use #12 AWG wire with 600-volt insulation and proper over-current circuit protection that complies with the local
codes. For specifications see Appendix C Specifications And Features on page 98.
Power Requirements (All currents are in amperes)
Model Number Description Qty Standby
Total
Standby
Alarm
Total
Alarm
FX-3500 FX-3500 FACP with Dialer X 0.390 = 0.630 =
ALC-636 636 Point Dual Loop Adder X 0.120 = 0.200 =
RAM-3500-LCD
Remote Annunciator with 4-
line LCD Display
X 0.070 = 0.100 =
RAX-LCD-LITE
Remote Annunciator with 4-
line LCD Display
X 0.065 = 0.080 =
PR-300
Polarity Reversal and City
Tie Module
X 0.050 = 0.300 =
SRM-312(W/R) Smart Relay Module X 0.030 = =
RAM-1016TZDS
16 Point Annunciator
Chassis
X 0.050 = 0.150 =
RAM-1032TZDS
32 Point Remote
Annunciator
X 0.050 = 0.300 =
RAX-1048TZDS
48 Point adder annunciator
display
X 0.022 =
1 zone active: 0.026
2 zone active: 0.030
3 zone active: 0.035
4 zone active: 0.039
48 zone active: 0.262
=
RTI-1
Remote Trouble Indicator,
Buzzer and LED
X .035 = .035 =
MIX-1251AP(A)
Advanced Protocol Ion
Smoke Detector (ULC)
X .0003 = .0050 =
MIX-2251AP(A)
Advanced Protocol Photo
Smoke Detector (ULC)
X .00036 = .0050 =
MIX-2251TAP(A)
Advanced Protocol Photo
Heat Detector (ULC)
X .00036 = .0050 =
MIX-2251TMAP(A)
Advanced Protocol
Acclimate Detector (ULC)
X .00036 = .0050 =
MIX-5251AP(A)
Advanced Protocol Heat
Detector (ULC)
X .0003 = .0050 =
MIX-5251HAP(A)
Advanced Protocol High
Temperature Heat Detector
(ULC)
X ==
MIX-5251RAP(A)
Advanced Protocol Rate of
Rise Heat Detector (ULC)
X ==
MIX-M500MAP(A)
Advanced Protocol Monitor
Module (ULC)
X .0004 = .0052 =
MIX-M500RAP(A)
Advanced Protocol Relay
Control Module (ULC)
X .0003 = .0051 =
MIX-M500SAP(A)
Advanced Protocol
Supervised Control Module
(ULC)
X .0004 = .0052 =
