Mircom FX-3500 - Figure 6 Installing the ALC-636 Dual Loop Adder; Table 11 ALC-636 Dual Loop Adder Connectors and Jumpers

29
Installation
Figure 6 Installing the ALC-636 Dual Loop Adder
Table 11 ALC-636 Dual Loop Adder Connectors and Jumpers
Item Setting
P1 Connect cable to P10 on the Main Board of the FX-3500.
Mounted on hex spacer
with four screws provided
ALC-636
A LOOP1
B
+
-
+
-
