FX-3500 Overview
MGD-32 Graphic Annunciator.
RAX-LCD-LITE Remote Annunciator with 4-line LCD Display.
AGD-048 Graphic Annunciator Adder Driver Board.
RTI-1
Common Remote Trouble Indicator, Buzzer and
LED.
BB-1001 White Enclosure for one annunciator.
BB-1001R Red Enclosure for one annunciator.
BB-1002 Enclosure for two annunciators.
Table 1 FX-3500 System Components (Continued)
