138
7521
7521
Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
9. SPARE PARTS LIST-5
Part Number Description Location(s)
286100202001 IC;T PA0202,AUDIO AMP,2W,T SSOP,24P U6
286302216001 IC;T PS2216,CARDBUS PWM CTRL,SSOP30P U13
284583601001 IC;W83601R,I2C TO GPIO,SSOP 20P U11
284583626001 IC;W83626F,LPC/ISA BRIDGE,PQFP,128P U31
273000114002 INDUCTER;4.7UH,10%,1206,SMT L522
273000990021 INDUCTOR;33uH,CDRH124,SMT PL506
346669600056 INSULAT OR 4X50X0.5;I/O BRACKET,RACE
346669600055 INSULAT OR 4X8X0.5;I/O BRACKET,RACE
346669600054 INSULAT OR;DC JACK,RACE
346669600071 INSULATOR;FDD BACK,RACE
346669600014 INSULATOR;INVERTER,REDSEA
346669600041 INSULAT OR;MEMORY,RACE
346670020001 INSULAT OR;PCMCIA,7521P
346669600039 INSULAT OR;T P BUTTON,RACE
346670020005 INSULAT OR;TV-OUT,7521P
531020237254 KBD;87,UI,K982318S1,W/EMI,7521
451670000058 LABEL KIT ;NON-BRAND,7521 MTC
242600000380 LABEL;10*8MM,BIOS,HI-TEMP 260
242600000380 LABEL;10*8MM,BIOS,HI-TEMP 260
242662300009 LABEL;25*10MM,3020F
242600000385 LABEL;27*10,LAN ID BAR CODE
242600000378 LABEL;27*7MM,HI-TEMP 260'C
242670020001 LABEL;AGENCY-GLOBAL,MTC,7521
242600000157 LABEL;BAR CODE & S/N,13.5*75,COMMON
242600000433 LABEL;BLANK,11*5MM,COMMON
Part Numbe r De s cription Location(s )
242664800013 LABEL;CAUTION,INVERT BD,PITCHING
242600000099 LABEL;MODEL,5M,MITAC
242600000001 LABEL;PAL,20*5MM,COMMON
242600000412 LABEL;PENTIUM,P WR SUIT E 3 NOTE BIOS
242668800033 LABEL;WINDOWS ME,CARTON,ORION2
242668820022 LABEL;WINDOWS ME/2000,ORION-3
441670020032 LCD ASSY;TFT,CHIMEI,14",7521P ID3C
451670020002 LCD ME KIT;T FT,CHIMEI,14",7521P ID3C
413000020266 LCD;N141X201,T FT,14",LVDS,XGA,CHIMEI
561567000001 MANUAL KIT ;EN,7521,NON-BRAND
561567000031 MANUAL;USER'S,EN,7521,NON-BRAND
421670000031 MICROPHONE ASSY;LCD,7521,MSL
412999900007 MODEM OPTION;UNIVERSAL,MDC,7521
416267002013 NB PLAT FORM;TFT,CHIMEI,14",7521P ID3C M
274042500405 OSC;25MHZ,50P PM,3.3V,15PF,H=1,SMALL OSC1
461670000015 PACKING KIT ;N-B,BOX,7521 MTC
221670050001 PART ITION;AK BOX,7521
221670050007 PART ITION;STOPER,AK BOX,7521
412155600048 PCB ASSY;MDM,56K,UNIV,W/O Y-CAP,7521
222600020049 PE BAG;50*70MM,W/SEAL,COMMON
222600020049 PE BAG;50*70MM,W/SEAL,COMMON
222667220003 PE BAG;L560XW345,CERES
222670000001 PE BUBBLE BAG;BATTERY,7521
340669600004 PLATE ASSY;T OUCHPAD,REDSEA
412670050004 PWA;PWA-7521 ID3C,QSB TRANS BD,MTC
