9. SPARE PARTS LIST-6
Part Number Description Location(s)
412670000005 PWA;PWA-7521,CHARGER TRANS BD MTC
412670000001 PWA;P WA-7521,HDD/FDD BD,T/U MTC
412670000004 PWA;PWA-7521,IQSB TRANS BD,T/U MTC
412670000002 PWA;PWA-7521,MDC TRANS BD,MTC
411670020002 PWA;PWA-7521P,MOTHER BD MTC
411670020004 PWA;PWA-7521P,MOTHER BD,SMT MTC
411670020003 PWA;PWA-7521P,MOTHER BD,T/U MTC
412670000006 PWA;PWA-INVERTER BD,7521,T/U,MTC
332810000033 PWR CORD;125V/7A,2P ,BLACK,AMERICA
271045157101 RES;.015 ,1W ,1% ,2512,SMT PR1,PR3,PR32,P R35
271045207101 RES;.02 ,1W ,1% ,2512,SMT PR68,P R2
271002000301 RES;0 ,1/10W,5% ,0805,SMT L507
271071000002 RES;0 ,1/16W,0603,SMT L52,L541,P R12,P R30,R1
1
271071100302 RES;10 ,1/16W,5% ,0603,SMT R163,R527,R154,R162
271071101301 RES;100 ,1/16W,5% ,0603,SMT R599
271071104101 RES;100K ,1/16W,1% ,0603,SMT PR18
271071104302 RES;100K ,1/16W,5% ,0603,SMT PR21,PR48,P R5,PR501,P
271071103101 RES;10K ,1/16W,1% ,0603,SMT PR26,PR27,P R37,P R38,P
271071103302 RES;10K ,1/16W,5% ,0603,SMT R127,R149,R150,R152,R
1
271071106301 RES;10M ,1/16W,5% ,0603,SMT R120
271071118271 RES;11.8K,1/16W,0.1%,0603,SMT PR61
271071111101 RES;110 ,1/16W,1% ,0603,SMT R553,R558
271071124102 RES;12.4K ,1/16W,1% ,0603,SMT PR47
271071124301 RES;120K ,1/16W,5% ,0603,SMT PR14
271071141102 RES;140 ,1/16W,1% ,0603,SMT R581
Part Numbe r De s cription Location(s )
271071143701 RES;14K ,1/16W,0.1% ,0603,SMT R30
271072151101 RES;150 ,1/10W,1% ,0603,SMT R519,R542,R547,R555,R
5
271071153101 RES;15K ,1/16W,1% ,0603,SMT PR45
271071153301 RES;15K ,1/16W,5% ,0603,SMT R140,R141,R142,R143,R
3
271071178311 RES;178K ,1/16W,1% ,0603,SMT R204
271071102302 RES;1K ,1/16W,5% ,0603,SMT PR22,P R39,R211,R29,R5
0
271071105101 RES;1M ,1/16W,1% ,0603,SMT R568,PR83
271071105301 RES;1M ,1/16W,5% ,0603,SMT PR13,P R64,PR72,PR73,
R
271071222302 RES;2.2K ,1/16W,5% ,0603,SMT R2,R3,R63,R169
271071272301 RES;2.7K ,1/16W,5% ,0603,SMT R128,R129,R130,R161,R
6
271071200101 RES;20 ,1/16W,1% ,0603,SMT PR75
271071203101 RES;20K ,1/16W,1% ,0603,SMT R35,R60,R228
271071221302 RES;22 ,1/16W,5% ,0603,SMT R103,R131,R132,R133,R
1
271071221301 RES;220 ,1/16W,5% ,0603,SMT R507,R557,R67
271071226311 RES;226K ,1/16W,1% ,0603,SMT P R16
271071249811 RES;24.9 ,1/16W,1% ,0603,SMT R254,R255,R257,R258
271071249311 RES;249K ,1/16W,1% ,0603,SMT P R65
271071202102 RES;2K ,1/16W,1% ,0603,SMT PR66,P R71
271071202301 RES;2K ,1/16W,5% ,0603,SMT PR44
271071205101 RES;2M ,1/16W,1% ,0603,SMT R571
271071316211 RES;31.6K,1/16W,1% ,0603,SMT PR55,P R81
271071330302 RES;33 ,1/16W,5% ,0603,SMT PR4,PR502,P R506,R112,
R
271071331301 RES;330 ,1/16W,5% ,0603,SMT R27,R508,R517,R548,R5
6
271071333301 RES;33K ,1/16W,5% ,0603,SMT PR23,P R509,R34,R61
271071357311 RES;357K ,1/16W,1% ,0603,SMT P R80
