Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
9. SPARE PARTS LIST-7
Part Number Description Location(s)
271071361101 RES;360 ,1/16W,1% ,0603,SMT R56
271071453111 RES;4.53K,1/16W,1% ,0603,SMT PR25
271013478301 RES;4.7 ,1/4W,5% ,1206,SMT L31,R21,R24
271002472301 RES;4.7K ,1/10W,5% ,0805,SMT PR9
271071472302 RES;4.7K ,1/16W,5% ,0603,SMT PR67,P R7,R106,R111,R1
4
271071499171 RES;4.99K,1/16W,0.1%,0603,SMT PR60
271071470301 RES;47 ,1/16W,5% ,0603,SMT PR51,R510,R511,R564,R
5
271071471302 RES;470 ,1/16W,5% ,0603,SMT R212,R525,R530,R533,R
5
271071474301 RES;470K ,1/16W,5% ,0603,SMT PR15,R188,R579,R7
271071473101 RES;47K ,1/16W,1% ,0603,SMT PR508,PR53
271071473301 RES;47K ,1/16W,5% ,0603,SMT R105,R65,R77
271071499811 RES;49.9 ,1/16W,1% ,0603,SMT R256,R259
271071562301 RES;5.6K ,1/16W,5% ,0603,SMT R189,R616,R98
271071565301 RES;5.6M ,1/16W,5% ,0603,SMT PR52
271071510301 RES;51 ,1/16W,5% ,0603,SMT R6
271071511102 RES;510 ,1/16W,1% ,0603,SMT PR77
271071511301 RES;510 ,1/16W,5% ,0603,SMT R541
271071564301 RES;560K ,1/16W,5% ,0603,SMT R19,R23
271071576311 RES;576K ,1/16W,1% ,0603,SMT R203
271071619111 RES;6.19K,1/16W,1% ,0603,SMT PR57
271071682101 RES;6.8K ,1/16W,1% ,0603,SMT R62
271071682301 RES;6.8K ,1/16W,5% ,0603,SMT R502,R503,R504,R505,R
5
271071619811 RES;61.9 ,1/16W,1% ,0603,SMT R176
271071681301 RES;680 ,1/16W,5% ,0603,SMT R513,R242,R243,R244,R
2
271071715311 RES;715K,1/16W,1%,0603,SMT PR19
Part Numbe r De s cription Location(s )
271071750101 RES;75 ,1/16W,1% ,0603,SMT R12,R13,R14,R15,R536,
R
271071822301 RES;8.2K ,1/16W,5% ,0603,SMT R177,R588
271071909101 RES;9.09K,1/16W,1% ,0603,SMT PR41
271071976111 RES;9.76K,1/16W,1% ,0603,SMT PR46
271071976311 RES;976K ,1/16W,1% ,0603,SMT R202
561567009001 REVISED PAGE;GN,7521,NO.1
271611000301 RP;0*4 ,8P ,1/16W,5% ,0612,SMT FA5
271571000301 RP;0*8 ,16P ,1/16W,5% ,1606,SMT RP27,RP28,RP29,RP45,
R
271611100301 RP;10*4 ,8P ,1/16W,5% ,0612,SMT RP40
271571100301 RP;10*8 ,16P ,1/16W,5% ,1606,SMT RP20,RP22,RP23,RP 25,
R
271611103301 RP;10K*4 ,8P ,1/16W,5% ,0612,SMT RP10,RP 13,RP39,RP61,
R
271621103303 RP;10K*8 ,10P ,1/16W,5% ,1206,SMT,TF RP16,RP18,RP 38,RP42,
R
271621102303 RP;1K*8 ,10P,1/16W,5% ,1206,SMT,TF RP35
271621102302 RP;1K*8 ,10P,1/32W,5% ,1206,SMT RP2
271611220301 RP;22*4 ,8P ,1/16W,5% ,0612,SMT RP17,RP21,RP24,RP26,
R
271611472301 RP;4.7K*4,8P ,1/16W,5% ,0612,SMT RP1,RP49,RP519,RP6
271621472303 RP;4.7K*8,10P,1/16W,5% ,1206,SMT,TF RP43,RP524
271621433301 RP;43K*8 ,10P ,1/16W,5% ,1206,SMT RP11,RP12,RP14,RP508,
271621560302 RP;56*4 ,8P ,1/16W,5% ,1206,SMT RP516
271571560302 RP;56*8 ,16P ,1/16W,5% ,1606,SMT RP3,RP4,RP5,RP501,RP
5
271611750301 RP;75*4 ,8P ,1/16W,5% ,0612,SMT RP15
345666600003 RUBBER;DOWN,LCD,T ITAN
345669600054 RUBBER;HDD_P CBA,RACE
565167000001 S/W;CD ROM SYSTEM DRIVER,7521
565180626001 S/W;CD*1,DVD,WIN-DVD,INTERVIDEO
