9. SPARE PARTS LIST-8
Part Number Description Location(s)
371102030301 SCREW;M2L3,FLT(+),NIB/NLK
371102030303 SCREW;M2L3,K-HEAD(+),NIW/NLK
371102030303 SCREW;M2L3,K-HEAD(+),NIW/NLK
371102030303 SCREW;M2L3,K-HEAD(+),NIW/NLK
371102030601 SCREW;M2L6,K-HEAD(+),NIB/NLK
371103030602 SCREW;M3L6,K-HEAD(+),NIB/NLK
340669600019 SHELDING ASSY;HDD,RACE
340669600016 SHIELDING ASSY;AUDIO,RACE
340670020010 SHIELDING ASSY;BOTTOM,7521P
340669600015 SHIELDING ASSY;CD ROM,RACE
346669600046 SHIELDING; MEMORY,RACE
346669600052 SPACER;HDD/FDD PCB,RACE
346669600016 SPACER;SOCKET 370,REDSEA
370102611802 SPC-SCREW;M2.6L18,K-HD,NIB/NLK
370102610405 SPC-SCREW;M2.6L4,NIW,K-HD,t=0.8,NLK
370102610405 SPC-SCREW;M2.6L4,NIW,K-HD,t=0.8,NLK
370102610405 SPC-SCREW;M2.6L4,NIW,K-HD,t=0.8,NLK
370102610603 SPC-SCREW;M2.6L6,K-HD,NIB/NLK
370102610603 SPC-SCREW;M2.6L6,K-HD,NIB/NLK
370102610804 SPC-SCREW;M2.6L8,K-HD,t=0.8,NIB/NLK
370102610804 SPC-SCREW;M2.6L8,K-HD,t=0.8,NIB/NLK
370102010204 SPC-SCREW;M2L2,NIW/NLK,K-HD
370102010256 SPC-SCREW;M2L2.5,K-HD(t0.5) NLK,NIW
370102010253 SPC-SCREW;M2L2.5,NIW/NLK,HD07
370102020301 SPC-SCREW;M2L3,NIW,K-HEAD
Part Numbe r De s cription Location(s )
370102010604 SPC-SCREW;M2L6,K-HD(+),NIW/NLK,HEAT
370103010405 SPC-SCREW;M3L4,NIW,K-HD,T0.3
340669600003 SPEAKER ASSY;REDSEA
345669600007 SPOGE; CPU,RACE
342669600011 STANDOFF;M2DP2H4L5,NIW,RACE
344669600037 STOP PER;CUP SOCKET,RACE
297120101005 SW;DIP,SPST,8P,50VDC,.1A,SMT,DHS4S SW3,SW4
297030105001 SW;P USH BUTTON,SPSD,48V/.05A,SMT SW2
297030102001 SW;T OGGLE,SPST,5V/0.2mA,H10.7MM,SMT SW1
346670000010 THERMAL PAD;HEATSINK,7521
346669600067 THERMALPAD;M/B,CHOCK,RACE
346669600006 THERMALPAD;SOCKET,RACE
340666600018 TILT UNIT ;L,TITAN
340666600017 TILT UNIT ;R,T ITAN
340670020011 TOP COVER ASSY;ID3C,7521P
442164900006 TOUCH PAD MODULE;T M41PUM220-2
288227002001 TRANS;2N7002LT1,N-CHANNEL FET PQ1,PQ12,P Q15,PQ16,P
