MiTAC 7521 PLUS/N - Page 62

61
7521
7521
Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
2.2.4 FDD/HDD Module
Disassembly
1. Carefully put the notebook upside down.
2. Remove one screw and slide the FDD/HDD module out of the compartment. (figure 2-8)
Figure 2-8
