72
7521
7521
Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
6. Remove six screws and two hexnut screws fastening the metal shield, and then lift the shield up
from the system board carefully. (figure 2-23)
Figure 2-23 Figure 2-24
7. Lift up the speaker assembly and disconnect the cable. (figure 2-24)
