Mitel Base Station - Page 21

32/1531-ANF 901 43 Uen B2 2016-04-01
Installation Guide
Base Station
19
6 Connect the coaxial cables to the MCX connectors on the base station.
7 Mount the base station (3), see 3.2.9 Mount the Base Station on page 21.
Figure 10. Connect external antennas.
Back view while lying down
MCX connectors
TOP
Min 74 mm
Max 250 mm
1
3
coaxial cable
lock nut
antenna
base station
antenna bracket
mounting bracket
2
TOP
