APPENDICES
APP − 41
Table 3.1 Special Relay List (Continued)
Number Name Stored Data Explanation
M9108
(Note-2)
Step transition monitoring
timer start(Corresponding
to D9108)
M9109
(Note-2)
Step transition monitoring
timer start(Corresponding
to D9109)
M9110
(Note-2)
Step transition monitoring
timer start(Corresponding
to D9110)
M9111
(Note-2)
Step transition monitoring
timer start(Corresponding
to D9111)
M9112
(Note-2)
Step transition monitoring
timer start(Corresponding
to D9112)
M9113
(Note-2)
Step transition monitoring
timer start(Corresponding
to D9113)
M9114
(Note-2)
Step transition monitoring
timer start(Corresponding
to D9114)
OFF Monitoring timer reset
ON Monitoring timer start
! Turned ON to start the timing of the step transition monitoring timer.
Turn OFF to reset the monitoring timer.
M9180
Active step sampling
trace completion flag
OFF Trace start
ON Trace completion
!
Turns ON at completion of sampling trace of all specified blocks, and
turns OFF at a sampling trace start.
M9181
Active step sampling
trace execution flag
OFF Trace not yet executed
ON Trace being executed
! Turns ON during execution of sampling trace, and turns OFF at
completion or stop.
M9182
(Note-2)
Active step sampling
trace enable
OFF Trace disable/stop
ON Trace enable
! Select whether to enable or disable sampling trace execution.
ON : Sampling trace execution is enabled.
OFF : Sampling trace execution is disabled.
Turn it OFF during sampling trace execution to stop trace.
M9196
(Note-2)
Operation output at block
stop
OFF Coil output OFF
ON Coil output ON
! Select the operation output at a block stop.
ON : The ON/OFF status of the coil used for the operation output of
the step executed at a block stop is retained.
OFF : All coil outputs are turned OFF. (The operation output provided
by the SET instruction is retained independently of whether
M9196 is ON or OFF.)
M9197 M9198 Display Range
OFF OFF X/Y0 to 7F0 states
ON OFF X/Y800 to FF0 states
OFF ON X/Y1000 to 17F0 states
ON ON X/Y1800 to 1FF0 states
M9197
•
M9198
Fuse blown-I/O verify
error indication switching
ON/OFF combination of M9197 and
M9198 is changed to switch indication.
!
The I/O module numbers of the fuse blown module indication (D9100
to D9107) and I/O module verify error indication (D9116 to D9123)
are changed.
!
Indication is changed at END.
M9199
Online sampling
trace/status latch data
restoration
OFF Data not restored
ON Data restored
! Restores the set data stored in the CPU to enable resumption of
sampling trace/status latch when it is executed.
! Turn M9199 ON when sampling trace/status latch is executed again.
(Data need not be written again by peripheral device.)
To Next Page
