MELSEC-A
3. SPECIFICATIONS
3 - 15
3.7 Applicable Encoders
The following encoders may be connected to the high-speed counter module.
(1) Encoders connectable to the AJ65BT-D62
(a) Open collector type encoder
(b) CMOS output type encoder
(Make sure that the output voltage of the encoder complies with the
specifications of the module.)
(2) Encoder connectable to the AJ65BT-D62D and AJ65BT-D62D-S1
(a) Line driver output type encoder
(Make sure that the output voltage of the encoder complies with the
specifications of the module.)
POINT
The following type of encoder cannot be used.
• TTL output type encoder
