When the system is started up for the rst time, the quick start
setting screen appears.
The items with an asterisk (*) cannot be edited when the lock
menu is on. (The icon changes to
when the lock menu is on.)
Note: State description indicated by toggle
Active;
, Inactive;
*1 For more details, refer to the installation manual of PAC-TH012HT(L)-E.
<Main Controller Menu Tree>
[Home screen]
[Menu]
[Manual operation]
[Function settings]
[Thermistor adjustment]
[Auxiliary settings]
[Heat source setting]
[Heat pump settings]
[Operation settings]
[Heating
operation]
[Hybrid
settings]
[Intelligent
settings]
[Pump speed]
[Economy settings for pump]
[Standard] (Heat pump & electric heater) / [Heater] (Electric heater only)/
[Boiler] / [Hybrid] (Heat pump & heater/Boiler)
[Electric heater (heating)]
[Mixing valve 1 control]
[Mixing valve 2 control]
[Flow sensor]
[Analogue output]
[Electric heater schedule]
[Electric heater (DHW)]
On/O󰀨
On/O󰀨
[Running]
[Running]
[Minimum]
[Priority]
[Daily schedule]
On/O󰀨
(Booster heater/Immersion heater)
[Delay]
[Delay]
[Heat pump ow rate range]
[Freeze stat function]
[Simultaneous operation]
[Cold weather function]
[Smart grid ready]
[Floor dry up]
[Boiler settings] *1
[Flow temperature range]
[Room temperature control]
[Heat pump thermo di󰀨.]
[Quiet mode] [Heating]
[Cooling]
[Quiet level] (Normal/Level1/Level2/Level3)
[Quiet level] (Normal/Level1/Level2/Level3)
[Minimum]
[Flow temp.]
On/O󰀨
On/O󰀨
On/O󰀨
On/O󰀨
[Start & End]
On/O󰀨
[Temperature increase step]
[Temperature decrease step]
On/O󰀨 (Heating)
[Electricity]
[Electricity]
[Heat pump capacity]
[Outdoor ambient temperature]
[Energy
price]
[CO
2
emission]
[Heat
source]
[Minimum temp.]
[Mode]
On/O󰀨
[Maximum]
[Ambient temp.]
[Ambient temp.]
[Ambient temp.]
[DHW]
On/O󰀨
[Heating]
[Target temperature]
[Cooling]
[Flow temperature
increase]
[Flow temperature
decrease]
[Pump cycles]
[Target temp.]
[Target temp.]
[Max temperature]
[Max temperature period]
[Target temp.]
[Increase interval]
[Decrease interval]
On/O󰀨 (Cooling)
[Interval]
[Boiler]
[Boiler]
[Boiler e󰀩ciency]
[Booster heater 1
capacity]
[Booster heater 2
capacity]
[Priority]
[Electricity
Schedule]
[Maximum temp.]
[Interval]
[Lower]
[Upper]
[Interval]
[Interval]
[Maximum]
[Interval]
[ Time schedule 1](Always/Start-Stop/Never)
[ Time schedule 2](Always/Start-Stop/Never)
[Delay]
Continued from the previous page.
<Continued to next page.>
[Service]*
[Ambient] /
[Cost] / [CO
2
]
