13-2. Engineers Forms
Commissioning/Field settings record sheet (continued from the previous page)
Main remote controller screen Parameters
Default
setting
Field
setting
Notes
Menu
Service Energy
monitor
settings
Electric heater
capacity
Booster heater 1 0 to 30 kW 2 kW
Booster heater 2 0 to 30 kW 4 kW
Immersion heater 0 to 30 kW 0 kW
Analogue output 0 to 30 kW 0 kW
Delivered energy adjustment −50 to +50% 0%
Water pump input Pump 1 0 to 200 W or ***(factory tted pump) ***
Pump 2 0 to 200 W 0 W
Pump 3 0 to 200 W 0 W
Pump 4 *7 0 to 200 W 72 W
Electric energy meter 0.1/1/10/100/1000 pulse/kWh 1000 pulse/kWh
Heat meter 0.1/1/10/100/1000 pulse/kWh 1000 pulse/kWh
External
in- put
settings
Demand control (IN4) Heat source OFF/Boiler operation Boiler operation
Outdoor thermostat (IN5) Heater operation/Boiler operation Boiler operation
Cooling limit temp.
(IN15)
Zone selection Zone 1/Zone 2/Zone 1&2 Zone 1
Zone 1 lowest temperature 5°C to 25°C 18°C
Zone 2 lowest temperature 5°C to 25°C 18°C
Thermo on output Zone 1/Zone 2/Zone 1&2 Zone 1&2
*1 The settings related to Zone 2 can be switched only when 2-zone temperature control or 2-zone valve ON/OFF control is active.
*2 The settings related to Zone 2 can be switched only when 2-zone temperature control is enabled (when DIP SW 2-6 and SW 2-7 are ON).
*3 Cooling mode settings are available for ERS* model only.
*4 Only available if DHW tank is present in system.
*5 When the indoor unit is connected with a PUMY-P outdoor unit, the mode is fixed to “Off”.
*6 For the model without both booster and immersion heater, it may not reach the set temperature depending on the outside ambient temperature.
*7 This setting is valid for only cylinder units.
*8 The lower limit is -15°C depending on the connected outdoor unit.
*9 The lower limit is -13°C depending on the connected outdoor unit.
*10 The lower limit is -14°C depending on the connected outdoor unit.
*11 On: the function is active; O󰀨: the function is inactive.
*12 Do not change the setting since it is set according to the specication of ow sensor attached to the indoor unit.
*13 When DIP SW1-1 is set to OFF “WITHOUT Boiler” or SW2-6 is set to OFF “WITHOUT Mixing tank”, neither Boiler nor Hybrid can be selected.
*14 Valid only when operating in Heating room temperature.
*15 When DIP SW5-2 is set to OFF, the function is active.
*16 If asterisk (**) is chosen freeze stat function is deactivated. (i.e. primary water freeze risk)
*17 When the indoor unit is connected with a PUMY-P and PXZ outdoor unit, the mode is fixed to “Ambient”.
*18 “*” of “*/kWh” represents currency unit (e.g. €, £, or the like)
*19 Valid only during heating mode
*20 To enable this function in the outdoor unit of PUZ-S(H)WM, switch the [Mode 7] in [Function settings] to "2".
([Menu] → [Service] → [Function settings], [Ref. add: 0], [Unit: 1] → [Mode 7], 1-High temperature control (default) / 2-Water temperature di󰀨erence control)
