2Unpacking to Installation
Setting the origin 2-21
(3) Preparing the T/B
Next, prepare to use the T/B
1) Set the mode of the controller to "MANUAL".
(The figure is example for CR750 controller)
2) Set the T/B [ENABLE] switch to "ENABLE". The menu selection
screen will appear.
The following operations are carried out with the T/B.
下：
ENABLE
*
ランプ点灯
上：DISABLE
Ｔ／Ｂ背面
Up: Disable
Down: Enable
(Lighting)
MODE
MANUAL AUTOMATIC
◇◆◇ Operating from the T/B ◇◆◇
Always set the mode of the controller to "MAMNUAL", and then set the T/B [ENABLE] switch to "ENABLE".
When the T/B is valid, only operations from the T/B are possible. Operations from the controller or external
signals will not be accepted.
