Mitsubishi ASX 2016

Passenger compartment (RHD
vehicles)
The fuse boxes in the passenger compartment
are located behind the glove box at the posi-
tion shown in the illustration.
A- Main fuse block
B- Sub fuse block
Main fuse block
1. Open the glove box.
2. Move the rod (A) on the left side of the
glove box to the left side of the box.
3. While pressing the side of the glove box,
unhook the left and right hooks (B) and
lower the glove box.
4. Remove the glove box fastener, and then
remove the glove box.
Sub fuse block
1. Remove the cover from the bottom of
the glove box.
Fuses
10-21
OGAE15E5
Maintenance
10
