*: Front of the vehicle
2. While pulling the tab (B), pull out the
socket (C).
3.
Turn the bulb (D) anticlockwise to re-
move it.
4. To install the bulb, perform the removal
steps in reverse.
NOTE
l
After installing the cap (A), make sure that
the mark (E) on the cap is pointing upward
and the cap is locked in place. If the cap is
not locked in place, it may become detached
while the vehicle is being driven.
Front turn-signal lamps
E01003802463
1. To create enough work space, turn the
steering wheel all the way in the direc-
tion opposite to the side you wish to re-
place.
2. Remove the screw (A), and then pull the
wheel cut moulding (B) to release the
three clips (C).
*: Front of the vehicle
CAUTION
l
Do not pull the wheel cut moulding (B)
more than necessary to release the three
clips (C). Otherwise, the wheel cut moulding
could break.
3. Remove the three clips (D), and then
pull back the splash shield (E).
Replacement of lamp bulbs
10-25
OGKE18E1
Maintenance
10
