*: Front of the vehicle
4. Turn the socket (F) anticlockwise to re-
move it, then remove the bulb from the
socket by turning it anticlockwise while
pressing in.
*: Front of the vehicle
5. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When refitting the clip (D), first insert part
(G) of the clip into the hole and then press
part (H) into it.
Front fog lamps*
E01004003544
1. To create enough work space, turn the
steering wheel all the way in the direc-
tion opposite to the side you wish to re-
place.
2. Remove the screw (A), and then pull the
wheel cut moulding (B) to release the
three clips (C).
*: Front of the vehicle
CAUTION
l
Do not pull the wheel cut moulding (B)
more than necessary to release the three
clips (C). Otherwise, the wheel cut moulding
could break.
3. Remove the three clips (D), and then
pull back the splash shield (E).
Replacement of lamp bulbs
10-26
OGKE18E1
Maintenance
10
