*: Front of the vehicle
4. While holding down the tab (F), pull out
the socket (G).
*: Front of the vehicle
5. Turn the bulb (H) anticlockwise to re-
move it.
6. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When refitting the clip (D), first insert part
(I) of the clip into the hole and then press
part (J) into it.
Rear fog lamp (driver’s side)/
Reversing lamp (Passenger’s
side)
E01004101697
1. Remove the three clips (A), and then
pull back the splash shield (B).
*: Rear of the vehicle
Replacement of lamp bulbs
10-27
OGKE18E1
Maintenance
10
