3. Turn the socket anticlockwise and re-
move it, and then pull the bulb out of the
socket.
C- Rear turn-signal lamps
D- Stop lamp (LED) - cannot be re-
placed
NOTE
l
The stop lamp use an LED instead of the
bulb.
If you need to repair or replace the stop
lamp, contact a MITSUBISHI MOTORS
Authorized Service Point.
4. To install the bulb, perform the removal
steps in reverse.
Licence plate lamps
E01004602312
1. Remove while pressing the lamp unit
(A) to the left side of the vehicle.
2. Insert a minus screwdriver with the end
covered with a cloth or other object to
press the hook (B) aside and remove the
lens.
3. Remove the bulb from the socket.
4. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the lamp unit, first insert the
end of tab (C) and then align tab (D).
Replacement of lamp bulbs
10-29
OGKE18E1
Maintenance
10
