Mitsubishi FX-1PG User Manual

< Terminal allocation >
FX-1PG FX 2N -1PG Function
SG -
Signal ground. Short-circuit it to SG terminal of PC.
STOP
DECELERATION STOP input.
Can function as stop command input in external command operation mode.
DOG
Offers following different functions depending on operation mode.
• Machine home position return operation: NEAR POINT SIGNAL input
• Interrupt single-speed operation: INTERRUPT input
• External command operation: DECELERATION START input
S/S
24V DC power terminal for STOP input and DOG input
Connected to sensor power supply of PC or external power supply.
PG0+
Power terminal for zero point signal
Connected to servo amplifier or external power supply (5 to 24V DC, 20 mA or less)
PG0-
Enters zero point signal from drive unit or servo amplifier.
Response pulse width: 4 µs or more
VH -
Power terminal for pulse output (supplied from servo amplifier or external unit)
24V DC±10% Current consumption: 15 mA
VL -
Power terminal for pulse output (supplied from servo amplifier or external unit)
5 to 15V DC Current consumption: 20 mA
- VIN
Power terminal for pulse output (supplied from servo amplifier or external unit)
5 to 24V DC, 35 mA or less
FP0 -
Pull-up resistance. Connected to VH or VL.
FP
Terminal which outputs forward pulse or pulses. 100 kHz, 20 mA or less (5 to 24V
DC)
COM0
Common terminal for pulse output
RP
Terminal which outputs reverse pulse or direction. 100 kHz, 20 mA or less (5 to
24V DC)
RP0 -
Pull-up resistance. Connected to VH or VL.
COM1
Common terminal for CLR output
CLR
Output for clearing deviation counter. 5 to 24V DC, 20 mA or less Output pulse
width: 20 ms(Output when return to home position is completed or LIMIT SWITCH
input is given.)
●
Spare terminal. Shall not be used a relay terminal.
3
FX-1PG/FX 2N -1PG PULSE GENERATOR UNIT TERMINAL ARRANGEMENT
3-2
