< Error code No. > [ BFM #29 ]
The following error code Nos. are saved in the BFM #29.
Read and check it when the BFM #28 b7 is set to 1 (Error
present).
OO1: Large/small relationship is incorrect. (V
max
<
Vbia or V
RT
<V
CR
)
OO indicates the lower word No. of the related
BFM.
OO2: Setting is not performed yet. (V(I), P(I), V(II) or
P(II))
However, V(II) and P(II) should be set
exclusively in two-speed operation or external
command operation.
OO indicates the corresponding BFM No. For
example, “172" indicates that the BFMs #18
and #17 are set to 0.
OO3: Setting range is incorrect.
OO indicates the corresponding BFM No. For
example, “043" indicates that the BFMs #5 and
#4 are set to a value outside the range of 10 to
100,000 PPS.
• When a speed command specifies a value
equivalent to or more than Vmax or a value
equivalent to or less than Vbia, error does not
occur. Vmax or Vbia is used for operation.
• Though the ready status can be specified even while
an error is present, the start command is not
accepted.
5
FX-1PG/FX
2N
-1PG PULSE GENERATOR UNIT BFM LIST
5-15
