30
Make sure that “SIMPLE TIMER” is displayed on the screen (at ).
(1) Press the
MENU
button to select
TIMER SET
:ENTER
on the screen (at ).
[Display
]
(2) Press the
ON/OFF
button to select “Start time only” or “Stop time only”.
• Start time only (Displays the time at which the air conditioner starts) : “Hr AFTER ON”
• Stop time only (Displays the time at which the air conditioner stops) : “Hr AFTER OFF”
(3) Press the [
CLOCK] buttons ( and ) to set the desired time. (The time can be set up to 72 hours in 1-hour
increments.)
[Display
]
* To cancel the time you have set, press the
CHECK
(CLEAR) button.
(4) Press the
FILTER
( ) button to confi rm the setting.
*1. When using only the start timer or stop timer, make sure that “– –” is displayed for the timer you are not going to use.
*2. To cancel the time you have set, press the
CHECK
(CLEAR) button to display “– –”, and then press the
FILTER
( )
button to confi rm it.
(5) When using both the start and stop timers, carry out steps (2) to (4) to set both the start and stop times.
* It is not possible to set the same time for both the start and stop times.
(6) Press the
MODE
button to complete the setting procedure.
[Set display example]
(7)Press the
ON/OFF
button. The simple timer will start to operate and the timer execution time you have set will be
displayed.
■
Display ex am ple
(7)
(6)
(1)
(3)
(2)
(4)
TIMER
MONITOR
TIMER SET
:ENTER
Hr
AFTER
ON Hr
AFTER OFF
1 2 71 72
Hr
AFTER
ON
Ten hours
SIMPLE
[Display ] [Display ]
How to Set the Simple Timer
If both start and stop timers are set, whichever time will come fi rst will be displayed.
