DC24V+8V
(-D,
-
DS
Type)
:
FZ-40: 25VA, FZ-60: 40VA
Power-failure compensation
:
20m.sec.
Ambient temperature
:
0-55OC (32- 13loF)
Storage temperature
:
-15-65OC
(5-
149OF)
Ambient humidity
:
85%
(no condensation)
Vi bration resistance
:
10
-
55H42,0.5rnm (Max. 2G1
In su
fa
tion resistance
:
5MCl (5OOVDC)
1
!
>
Insulation withstand voltage
:
1500VAC, 1 minu.
i
I
i
1
CPU
Memory
I
,,I'
-,_
~~
__
~
Method
:
Stored program, Repeated arithmetic
Program language
:
Relay and logic sym bok
Functional instructions
:
35
2:
i
-rota'
57
Instructions
:
Sequenciat instructions
:
Step-ladder instructions
:
Program capacity
:
1000 steps
Execution speed
:
Average 7p.sec/step
Memory
:
C-MOS RAM standard, EP-ROM option
CPU
:
p.p
8031
Self-d iagnostics
:
Sum-check, watch-dog timer, battery voltage,
Battery
:
Lithium battery
power supply voltage, etc.
Functional
Number
of
input
:
F2-40 (Base unit): 24 points (W/RUN, STOP inputs)
F2-60
(Base
unit): 36 points (W/RUN, STOP inputs)
Number
of
output
F2-40 (Base unit): 16 points
(W/RUN
contact)
F2-60
(Base
unit):
24
points (W/RUN contact)
Input sensor power
Timers
Counters (backed by battery)
:
Auxiliary relays
:
F2-40 (Base unit): 24VDC 0.25A total (All inputs turned OFF)
~2-60
(Base unit): 24VDC 0.43A total (ditto)
:
0.1
-
999
sec.
timer: 24 points
(3
digits)
0.01
-
99.9
sec. timer: 8 points (3 digits)
1
-
999:
32
points Up/down available
No
battery back-up
:
128 points (M100- M277)
Backed by battery
:
64
points (M300
-
M377)
State
:
40 points (M600
-
M647)
JM
P/EJP
:
64 points (M700
-
M777)
-
24
-
