Mitsubishi MELSEC Q Series Handbook

3 ETHERNET INTERFACE MODULE REPLACEMENT
3 - 18
: compatible, : partial change required, ×: Incompatible
Output signal
Signal name
Compat-
ibility
Precautions for
replacement
QnA series QnAS series Q series
AJ71QE71N3-T
AJ71QE71N-B5
AJ71QE71N-B2
A1SJ71QE71N3-T
A1SJ71QE71N-B5
A1SJ71QE71N-B2
QJ71E71-100
QJ71E71-B5
QJ71E71-B2
Yn0 Transmission request or reception end check (For connection No.1)
Yn1 Transmission request or reception end check (For connection No.2)
Yn2 Transmission request or reception end check (For connection No.3)
Yn3 Transmission request or reception end check (For connection No.4)
Yn4 Transmission request or reception end check (For connection No.5)
Yn5 Transmission request or reception end check (For connection No.6)
Yn6 Transmission request or reception end check (For connection No.7)
Yn7 Transmission request or reception end check (For connection No.8)
Yn8 Open request (For connection No.1)
Yn9 Open request (For connection No.2)
YnA Open request (For connection No.3)
YnB Open request (For connection No.4)
YnC Open request (For connection No.5)
YnD Open request (For connection No.6)
YnE Open request (For connection No.7)
YnF Open request (For connection No.8)
Y(n+1)0
E
2
PROM read request
Use prohibited
No E
2
PROM
(Refer to Section 3.8.)
Y(n+1)1
E
2
PROM write request
Y(n+1)2
Use prohibited
Y(n+1)3
Y(n+1)4
Y(n+1)5
Y(n+1)6
Y(n+1)7 COM. ERR LED OFF request
Y(n+1)8 Use prohibited
Y(n+1)9 Initial request
Y(n+1)A
Use prohibited
Y(n+1)B
Y(n+1)C
Y(n+1)D
Y(n+1)E
Y(n+1)F
