Mitsubishi MELSEC Q Series Handbook

3 ETHERNET INTERFACE MODULE REPLACEMENT
3 - 17
(2) Comparison between QnA/QnAS series and Q series
: compatible, : partial change required, ×: Incompatible
Input signal
Signal name
Compat-
ibility
Precautions for
replacement
QnA series QnAS series Q series
AJ71QE71N3-T
AJ71QE71N-B5
AJ71QE71N-B2
A1SJ71QE71N3-T
A1SJ71QE71N-B5
A1SJ71QE71N-B2
QJ71E71-100
QJ71E71-B5
QJ71E71-B2
Xn0 Transmission normal end or reception end (For connection No.1)
Xn1 Transmission error detection or reception error detection (For connection No.1)
Xn2 Transmission normal end or reception end (For connection No.2)
Xn3 Transmission error detection or reception error detection (For connection No.2)
Xn4 Transmission normal end or reception end (For connection No.3)
Xn5 Transmission error detection or reception error detection (For connection No.3)
Xn6 Transmission normal end or reception end (For connection No.4)
Xn7 Transmission error detection or reception error detection (For connection No.4)
Xn8 Transmission normal end or reception end (For connection No.5)
Xn9 Transmission error detection or reception error detection (For connection No.5)
XnA Transmission normal end or reception end (For connection No.6)
XnB Transmission error detection or reception error detection (For connection No.6)
XnC Transmission normal end or reception end (For connection No.7)
XnD Transmission error detection or reception error detection (For connection No.7)
XnE Transmission normal end or reception end (For connection No.8)
XnF Transmission error detection or reception error detection (For connection No.8)
X(n+1)0 Open end (For connection No.1)
X(n+1)1 Open end (For connection No.2)
X(n+1)2 Open end (For connection No.3)
X(n+1)3 Open end (For connection No.4)
X(n+1)4 Open end (For connection No.5)
X(n+1)5 Open end (For connection No.6)
X(n+1)6 Open end (For connection No.7)
X(n+1)7 Open end (For connection No.8)
X(n+1)8 Open error detection
X(n+1)9 Initial normal end
X(n+1)A Initial error end
X(n+1)B Use prohibited
X(n+1)C COM. ERR LED ON
X(n+1)D
E
2
PROM read complete
Use prohibited
No E
2
PROM
(Refer to Section 3.8.)
X(n+1)E
E
2
PROM write complete
X(n+1)F Watchdog timer error detection
