COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES
(1) Method of ensuring compliance
To ensure that Mitsubishi programmable controllers maintain EMC and Low
Voltage Directives when incorporated into other machinery or equipment, certain
measures may be necessary. Please refer to one of the following manuals.
• QCPU User's Manual (Hardware Design, Maintenance and Inspection)
• Safety Guidelines (this manual is included with the CPU module or base unit)
The CE mark on the side of the programmable controller indicates compliance
with EMC and Low Voltage Directives.
(2) Additional measures
To ensure that this product maintains EMC and Low Voltage Directives, please
refer to Section 4.3.1.
GENERIC TERMS AND ABBREVIATIONS
Unless specially noted, the following generic terms and abbreviations are used in this
manual.
Generic term/abbreviation Details of generic term/abbreviation
CPU module Generic term for CPU module on which QD75 can be mounted.
QD75 Generic term for positioning module QD75P1N, QD75P2N, QD75P4N, QD75D1N, QD75D2N,
QD75D4N, QD75P1, QD75P2, QD75P4, QD75D1, QD75D2, and QD75D4.
The module type is described to indicate a specific module.
QD75P N Generic term for positioning module QD75P1N, QD75P2N, QD75P4N.
QD75D N Generic term for positioning module QD75D1N, QD75D2N, QD75D4N.
QD75P Generic term for positioning module QD75P1, QD75P2, QD75P4.
QD75D Generic term for positioning module QD75D1, QD75D2, QD75D4.
Peripheral device Generic term for DOS/V personal computer that can run the following "GX Developer" and
"GX Configurator-QP".
GX Configurator-QP Abbreviation for GX Configurator-QP (SW2D5C-QD75P-E or later).
GX Developer Abbreviation for GX Developer (SW4D5C-GPPW-E or later).
GX Works2 Product name of the software package for the MELSEC programmable controllers.
Drive unit (servo amplifier) Abbreviation for pulse input compatible drive unit (servo amplifier).
Manual pulse generator Abbreviation for manual pulse generator (prepared by user).
DOS/V personal computer
IBM PC/AT
®
and compatible DOS/V compliant personal computer.
Personal computer
Generic term for personal computer which supports Windows
®
.
Workpiece Generic term for moving body such as workpiece and tool, and for various control targets.
Axis 1, axis 2, axis 3, axis 4 Indicates each axis connected to QD75.
1-axis, 2-axis, 3-axis, 4-axis Indicates the number of axes. (Example: 2-axis = Indicates two axes such as axis 1 and axis
2, axis 2 and axis 3, and axis 3 and axis 1.)
