2 ENGINE - OUTLINE
Mitsubishi Diesel Engine S12R OPERATION & MAINTENANCE MANUAL
78
Pub. No. 291Y1-40720 Revision: 5
S12R-Y1PTA2-1, S12R-Y1PTA2-2
■ Engine Front View, Engine Rear View
No. Name No. Name
Engine body
(1) Damper
Cooling system
(9) Coolant outlet
(2) Flywheel (10) Thermostat case
Fuel system (3) Governor actuator (11) Water pump
Lubrication system
(4) Breather (12) Intake port
(5) Bypass oil filter
Inlet and
exhaust systems
(13) Turbocharger
(6) Oil pan (14) Exhaust outlet
(7) Engine oil drain port
(8) Oil pump
(13)
(12)
(13)
(14)
(12)
(3)
(2)
(7)
(9)
(10)
(9)
(10)
(4)
(1)
(11)
(8)
(7) (6)
(5)
To Next Page
