11 TROUBLESHOOTING

Mitsubishi Diesel Engine S12R OPERATION & MAINTENANCE MANUAL

192

Pub. No. 291Y1-40720 Revision: 5

During Normal Operation, Thermo Switch Activated

Table 11-13 During Normal Operation, Thermo Switch Activated

Problem Cause Remedies Reference

Page

During Normal Opera-

tion, Thermo Switch Ac-

tivated

Coolant temperature

raised

Restart the engine in the following order: -

1 Operate the engine at low idle

speed to cool down

immediately.

2 Stop the engine.

3 Check the coolant level.

4 Check the ambient

temperature.

5 Bleed air from the cooling

system.

6 Check the radiator, fan, and

fan belt.

7 Check the coolant

temperature.

8 If no fault has been found,

restart the engine.

• If any fault is found, contact

your MHIET dealer "

CONTACT

LIST" (→ Page 10).
