ENGINE INSPECTION RECORD SHEET
No.5
S3Q2,S3Q2-T
Inspection
Item
Unit
Measurement of Oil Clearance of Connecting Rod Bearing
DateCustomer
Measured by
Remarks
Model
Engine Serial No.
Approved by
Examined by
Standards
mm [in.]
58.000 to 58.045
[2.2835 to 2.2852]
Connecting rod bearing oil clearance
φ58
[2.28]
57.950 to 57.970
[2.2815 to 2.2823]
Connecting rod bearing inside
diameter
Crankshaft pin outside diameter
−
Nominal value Standard Limit
−
0.030 to 0.095
[0.0012 to 0.0037]
0.200
[0.0079]
Oil clearance
φ58
[2.28]
XYZX
−
Crankshaft pin outside
diameter
Y
Name Connecting rod bearing inside diameter
①
②
①
②
Measured values
Measuring positions
3
2
1
No.
Position
①
②
Ԙ
ԙ
Z
Y
X
X
Y
Ԙ
ԙ
