SERVICE TOOLS
3-2
1. General tools
General tools
1234
56
910
78
Table 3-1 General tool list
No. Tool name Part No. Use
- Tool set 32A91-00010 Includes parts No.1 through 10
1 Tool bag 34491-01102
2 Spanner F9600-10012 Width across flats: 10 × 12 mm [0.39 × 0.47 in.]
3 Spanner F9600-14017 Width across flats: 14 × 17 mm [0.55 × 0.67 in.]
4 Spanner F9600-22024 Width across flats: 22 × 24 mm [0.87 × 0.94 in.]
5 Wrench F9612-12014 Width across flats: 12 × 14 mm [0.47 × 0.55 in.]
6 Screw driver 91267-00201 (+), (-)
7 Socket F9614-17000 Width across flats: 17 mm [0.67 in.]
8 Socket F9614-19000 Width across flats: 19 mm [0.75 in.]
9 Handle F9618-25000
10 Extension bar F9615-15000
