Chapter 12 MAIN SPECIFICATIONS
Main specifications
Note: (a) The specification above are subject to change without prior notice.
(b) The special specification may differ according to the above standard specification.
Table 12-1 Main specifications
Item Specifications
Engine model S6B
Type Water-cooled 4-stroke cycle, turbocharged with air cooler
Number of cylinders, arrangement 6-in-line cylinders
Bore×Stroke ø135 × 150 mm [5.31 × 5.90 in.]
Total displacement 12.9 L [787 cu. in.]
Combustion type Direct injection system
Compression ratio 14.2 : 1 or 14.8 : 1
Firing order 1 - 5 - 3 - 6 - 2 - 4
Rotation direction Counterclockwise as viewed from flywheel side
Dimensions (L×W×H)
Approx. 1558 mm × 878 mm × 1268 mm
[411.58 in. × 231.94 in. × 334.97 in.]
Dry weight Approx. 1350 kg [2976 lb.]
Fuel Diesel fuel
Fuel injection pump BOSCH S3000, S3S or S7S
Governor Mechanical, mechanical hydraulic or electrical type
Fuel filter Paper-element type
Fuel injection nozzle Hole type
Initial fuel injection pressure 21.57 MPa {220 kgf/cm
2
} [3129 psi]
Lubricating system Forced lubrication (pressure feed by oil pump)
Lubrication oil Class CF oil (API service classification)
Engine oil capacity
Oil pan: approx. 40 L [10.57 U.S. gal.],
whole engine: approx. 50 L [13.21 U.S. gal.]
Oil filter Paper-element type
Oil cooler Water cooled multi-plate
Cooling system Forced water cooling
Cooling water capacity Approx. 30 L [7.93 U.S. gal.] (in engine only)
Starting system Electrical or pneumatic type
Starter 24V DC - 6kW
Alternator 24V DC - 30 A
Turbocharger Mitsubishi 4LF, TD08, TD09 or TD10
Flywheel Equivalent of SAE. 14in
Flywheel housing Equivalent of SAE. No.1
