3-9
Chapter 3 OPERATION
Fuel tank oil level - Check
Make sure the fuel tank is full.
If the fuel level is low, refill the tank to the "FULL" level.
Engine oil level - Check
1. Pull out the oil level gauge and wipe it clean using
a waste cloth.
2. Insert the oil level gauge fully into the oil level
gauge guide, then pull out the gauge again.
3. The correct oil level is between the MAXIMUM and
MINIMUM marks on the oil level gauge.
4. If the oil level is low, remove the oil filler cap and
add engine oil of the specified type to the MAXI-
MUM level.
5. Install the oil filler cap after refilling.
6. Check the oil pan and other area for oil leaks.
Fig. 3-14 Oil filler and oil level gauge
When working around fuel, make sure there are no open flames, heaters or other fire hazards.
Wipe off any spilled fuel completely. Spilled fuel can ignite and cause a fire.
Do not remove the strainer when filling the fuel tank.
For fuel to be used, refer to "FUEL" (4-1).
Oil filler
Oil level gauge
