4-1
Chapter 4 FUEL
Recommended fuel
Use a diesel fuel that meets "ASTM diesel fuel oil
No.2-D" (JIS K2204 diesel fuel).
It is necessary to use fuel that has a pour point suit-
able for the ambient temperature. Choose the fuel
type from the following chart.
Fig. 4-1 Recommended fuel
Fig. 4-2 Recommended fuel according to ambient
temperature
Handling fuel
When using fuel stored in a storage tank, leave it to sit for more than 24 hours so that dust and water can settle at
the bottom. Then, use the upper clean fuel.
Fill up the fuel tank or service tank after each operation.
This prevents water from mixing with fuel in the tank and also gives time for dust and water to separate and settle at
the bottom of the tank.
Before refilling, clean the areas around the caps thoroughly and remove the caps from the drum and tank. Also
clean your hands and the hose before refueling. When using a hand-operated pump, be careful not to pump water
or sediment accumulated at the bottom of the storage tank.
Be sure to use a strainer when filling fuel tank. For a complete filtration, it is recommended to use a clean lint-free
cloth together with the strainer.
Use the recommended fuel specified in this manual.
Do not refill the fuel tank more than the specified
level, as it may result in a fire.
Table 4-1 Recommended fuel
Specification Classification
JIS K2204, 2205 TYPE 1, TYPE 2, TYPE 3
ASTM D975 No.1-D, No.2-D
BS 2869 CLASS A1, CLASS A2
DIN 51601 DIESEL-FUEL
ISO 8217 DMX-CLASS
Diesel fuel
In
Compliance
with
JIS K2204
[-21] [-4] [14] [32] [50] [68] [86] [104]
Special No. 3
No. 3
No. 2
No. 1
Special No. 1
Diesel fuel
