3-12
Chapter 3 OPERATION
Temperature of damper - Check
Damper temperature management by
thermo label
It is recommended to use the thermo label for temper-
ature management of the damper in regular use
engine. Check the thermo label before starting engine.
1. Check the thermal part of thermo label is black.
2. Note the highest temperature of thermal part. Note
the temperature periodically, and check the abnor-
mality of temperature alteration.
Note: For damper inspection, refer to "Damper - In-
spect" (8-3).
Fig. 3-22 Thermo label of damper
If the abnormality of temperature alteration is found,
consult a Mitsubishi dealer.
5E-75!
75 80 85 90 95
5E-100!
100 105 110 115 120
5E-50!
50 55 60 65 70
Thermo label
75ºC [167ºF]<Damper temperature
<80ºC [176ºF]
