SERVICE DATA
2-7
1.5 Cooling system
1.6 Inlet and exhaust system
Table 2-5 Maintenance service data table - Cooling system Unit: mm [in.]
Inspection point Nominal Standard Limit Remark
Thermostat
Temperature at which valve starts
opening
76.5 ± 1.5°C
[170 ± 3.5°F]
Temperature at which valve lift is
9 [0.35], minimum
90 ± 1.5°C
[194 ± 2.7°F]
Table 2-6 Maintenance service data table - Inlet and exhaust system Unit: mm [in.]
Inspection point Nominal Standard Limit Remark
Distortion of exhaust manifold
0.2
[0.008] or less
Repair by grinding or replace.
Axial clearance of cartridge assembly
0.057 to 0.103
[0.0022 to 0.0041]
