OPERATION
55
EN
(3) Carefully pull out and completely remove (4) Carefully unravel the new liner
the liner.
(5) Carefully feed in the new liner down the torch (6) Fit the liner retaining nut and screw
lead all the way to exit the torch neck. only 1/2 way down.
(7) Snip the liner off 3mm past the end of the (8) Replace the front end parts.
torch neck.
(9) Fully screw down the liner retaining nut and
