Description of the unit
10 Operating instructions
3 Description of the unit
3.1 Overview of the unit
g
b
h
i
c
d
ef
a
j
Image: Salamander Vario Intelligence
a Power connection f Collection container
b Handle g Unit cover
c Nameplate h Contact plate
d Operating elements i Contact cover
e Grate j Heating unit
1001247120ABBE-C
