Setup Cha
p
ter Two: Installation
24
15-Pin Type "D"
Connector
B
DIA
A
DIA
C
Type 253B-2-50-2 Shown
1.44
(36.5)
Driver/Gear
Assembly
Figure 2: Type 253 Valve with a KF Style ISO Flange
15-Pin Type "D"
Connector
0.39
(9.9)
B
DIA
A
DIA
D
DIA Hole Throu
g
h
Type 253B-3-80-2 Shown
C
Driver/Gear
Assembly
Figure 3: Type 253 Valve with a NW Style ISO Flange
