MKS T3B Series User Manual

Chapter Two: RS-232 Message Summary
52
T10 Setpoint A = Position
T11 Setpoint A = Pressure
T20 Setpoint B = Position
T21 Setpoint B = Pressure
T30 Setpoint C = Position
T31 Setpoint C = Pressure
T40 Setpoint D = Position
T41 Setpoint D = Pressure
T50 Setpoint E = Position
T51 Setpoint E = Pressure
T60 Analog Setpoint = Position
T61 Analog Setpoint = Pressure
U0 Set sensor type Absolute
U1 Set sensor type Differential
USR Set Operating Mode = USER
V0 Set Pressure Control Mode = Model Based
V1 Set Pressure Control Mode = PID
W1 Set Controller Phase or Lead
W90
Clear Battery Stats  (T3P
only)
X1 Set Phase Setpoint A Value
X2 Set Phase Setpoint B Value
X3 Set Phase Setpoint C Value
X4 Set Phase Setpoint D Value
X5 Set Phase Setpoint E Value
X6 Set Phase Analog Setpoint Value
X7 Set Local preset pressure phase
Y1
Calibrate Analog Input Full Scale
Y2
Set Full Scale Analog Setpoint
Y3
Calibrate Analog Full Scale 
Y4
Calibrate Analog Zero 
Z1 Commence Zero Calibration (corrects sensor
zero offsets)
Z2 Zeros Base Pressure
Z3 Removes Z1 and Z2 Value
Z4 Set Zero Analog Setpoint
ZZ Start or Stop DeviceNet Services (toggles)

= Indicates that the instrument must be set to the
calibration mode in order to process this command.
 = Indicates a factory only setting.
