TECHNICAL SPECIFICATIONS
All specifications are nominal and subject to change without notice. A specification
referred to as “typical” is within ±20% of a stated value at room temperature
(25°C/77°F) and utilizing a sufficiently charged battery pack.
DEVICE PARAMETERS
Power Parameters
Power Supply: 12 VDC
Rechargeable Lithium-Ion
Battery Pack: 3-cell 2.6AH Battery Pack
BMS overcharge Protection
Battery Charger: 12.6VDC, 1.8amp output
Charge Time: 2-3 hours
Full-Charge Activation: Until low-battery indicator illuminates
Power Output: 49 Watts
LED Light White Cool 5700K
Digital Colposcope
Working Distance: 17-40cm
Focus Mechanism: Manual
Optical Magnification 3x
Digital Magnification: 3x-9x
Field of View: 15.6°
Direction of View:
F#: >5
Average On-Axis Vertical Resolution: 15.75 line-pairs/mm
Average On-Axis Horizontal Resolution: 15.75 line-pairs/mm
Average Off-Axis Vertical Resolution: 11.56 line-pairs/mm
Average Off-Axis Horizontal Resolution: 10.33 line-pairs/mm
Image Resolution Pixels: 2016 X 2880 (5.8 megapixels)
Display
Display area:
62.10(H) X 110.40(V)
5.0in Diagonal
Number of Pixels:
720 X 1280
(0.92
megapixels
)
Display Colors:
16.7M colors
Dimensions and Weight
Width: 3.2 inches (8cm)
Height: 9.5 inches (24cm)
Depth: 4.5 inches (11.5 cm)
Weight: 15.4 oz (435g)
Operating Conditions
Ambient Temperature: 10°C to 40°
