2.2 Mobileye 5 Connections Description
The following paragraphs describe in detail the function of the cables and
connections shown above.
2.2.1 Mobileye 5 Main unit connections
The Mobileye 5 main unit contains the camera, the Audio Buzzer and the main
processor (EyeQ™). The Mobileye 5 main unit also contains volume control buttons.
The Mobileye 5 Main unit functions as a Universal Mounting Adapter for all vehicles’
front windshield angles. It is attached to the vehicle’s front windshield with the
provided 3M double sided sticker.
The Mobileye 5 Connecting cable is split into a few various cables which are used to
connect to the vehicle power source, to the vehicle CAN-bus, to the vehicle High-
beams (for IHC) and to the Mobileye EyeWatch display and Control unit and
Mobileye EyeCAN.
A detailed description of each Mobileye 5 connecting cable connections can be
found in the table below:
Wire Name & Function
Wire color
Connector
Connection To
EyeCAN - ( 6 pin connector)
Black
P2
EyeCAN unit (for system calibration)
EyeWatch - (4 pin connector)
Black
J1
EyeWatch Display & Control unit
BAT+ (12/24V)
Red
-
Vehicle constant power (Battery)
GND
Black
-
Vehicle GND (BAT-)
Ignition (12/24V)
Blue
-
Vehicle Ignition signal
CAN B H
White
-
Vehicle CAN-bus (CAN High wire)
CAN B L
Yellow
-
Vehicle CAN-bus (CAN Low wire)
IHC – (Analog Output)
Gray
-
Vehicle High-beams via external Relay
AUX
Pink
-
Future option
Table 1: Mobileye 5 connecting cable connections
