2 Mobileye 5 Description
WARNING: The Mobileye 5™ system should be installed ONLY by Mobileye® Technologies Ltd.
authorized personnel!
2.1 Mobileye 5 Components overview
The Mobileye 5 is based on the following elements:
 The Mobileye 5 Main Unit and Connector Cable (Camera)
 The EyeWatch Display & Control Unit (Optional)
When receiving the Mobileye 5 please verify receiving & identify all the following
components:
2.1.1 Mobileye 5 Main Unit & connecting cable (CAB000105)
The Mobileye 5 Main Unit contains the following components:
Camera unit, High-quality Audio Alert Buzzer, Mobileye Chip on Board system
(SeeQ), Connector Cable.
Figure 1: Mobileye 5 with connecting cable – Front view.
