Mobileye 5 – Technical Installation Guide_Rev 0.3
Jan, 2012
Page 12 of 38
Mobileye Proprietary and Confidential
support@mobileye.com
3 Mobileye 5 Installation
3.1 Electrical Vehicle Signals Requirements
Table 4 details the Mobileye 5 requirements regarding which vehicle signals are
needed, and what their electrical attributes should be.
Please make sure the vehicle to-be-installed complies with these requirements
Item
Description
Value
Signals Cables
Car inputs
BAT+, GND, Ignition, High Beam, CAN-Bus
(High/Low)
Voltages
Input
12 - 36VDC
Current Load (full operation)
12v > 360mA, 24v > 180mA**
Stand-by Current Load (Ignition off)
12v > 10mA, 24v > 10mA
Power consumption
Nominal 5.2W
* A 12V vehicle has battery voltage of 13.7V and 24V vehicle has battery voltage of 27V.
** The current consumption of the Mobileye 5 is depended on the vehicle system voltage (12 or 24V).
Additional Notes:
1. Mobileye 5 complies with automotive standard (ISO-7637-2) regarding voltage transients for all
signals (input voltage and car signals).
